K9F1208Q0A K9F1216Q0A
K9F1208D0A K9F1216D0A
K9F1208U0A K9F1216U0A
FLASH MEMORY
Input Data Latch Cycle
tCLH
CLE
tCH
CE
tWC
tALS
ALE
tWP
tWP
tWP
WE
tWH
tDH
tDH
tDH
tDS
tDS
tDS
I/Ox
DIN 0
DIN 1
DIN n
Serial access Cycle after Read(CLE=L, WE=H, ALE=L)
tRC
CE
tCHZ*
tOH
tREH
tREA
tREA
tREA
RE
tRHZ*
tOH
tRHZ*
I/Ox
Dout
Dout
Dout
tRR
R/B
NOTES : Transition is measured ±200mV from steady state voltage with load.
This parameter is sampled and not 100% tested.
