LSH 20-150
Storage
l It is recommended to maintain the storage area clean, ventilated and
°
preferably not exceeding 30 C
Warning
l Fire, explosion and burn hazard
°
°
l Do not recharge, short circuit, crush, disassemble, heat above 150 C (302 F),
incinerate, or expose contents to water
61.70 max
Typical discharge curve under 100 mA
3.9
3.7
3.5
3.3
3.1
2.9
2.7
Ø 32.05 max
Dimensions in mm.
2.5
2.3
2.1
1.9
+ 125°C
+ 80°C
+ 25°C
– 20°C
–
40°C
+ 150°C
Shocks and vibrations
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
l Ability to withstand in the entire
operating temperature range
750 G peak/0.5 msec repetitive
shocks on axial and radial axes
(undischarged and partially
discharged cells)
Capacity (Ah)
Typical discharge curve under 100, 200 and 300 mA at +150ºC
3.9
3.7
3.5
3.3
3.1
2.9
2.7
2.5
2.3
2.1
1.9
l Ability to withstand in the entire
operating temperature range
20 GRMS random vibrations
300 mA
200 mA
100 mA
2 to 4 hours along X, Y and Z axis
< 30 Hz
@≥ 6 dB/octave
30-80 Hz
80-300 Hz
@
@
3 dB/octave
0 dB/octave
300-1000 Hz @ -3 dB/octave
l Ability to withstand in the entire
operating temperature range
1 hour of linear sine sweep at
30 G peak, from 30 to 2000 Hz
along X, Y and Z axis
0
1
2
3
4
5
6
7
8
10
11
12
13
14
15
9
Capacity (Ah)
