Specifications
INPUT SPECIFICATIONS:
Input Voltage Range..........................................................................................................................................................12V....................................................9-18V
24V..................................................18-36V
48V..................................................36-72V
Input Filter....................................................................................................................................................................................................................................Pi Type
15 WATT WIDE INPUT
DC-DC CONVERTERS
Features
• 15W Isolated Output
• 2:1 Input Range
• Six-Sided Shield
• Remote ON/OFF Control
• Efficiency to 84%
• 200KHz Switching Frequency
GENERAL SPECIFICATIONS:
Efficiency.......................................................................................See Table
Isolation Voltage.....................................................................500 VDC min.
Isolation Resistance........................................................................10
9
ohms
Switching Frequency................................................................200KHz, typ.
Operating Temperature Range.......................................-25°C to + 71°C
Case Temperature....................................................................100˚C max.
Cooling........................................................................Free-Air Convection
Storage Temperature Range..........................................-55°C to + 105°C
EMI/RFI.............................................................Six-Sided Continuous Shield
Dimensions..............................................................2.56 x 3.0 x 0.83 inches
(65 x 76.2 x 21.1 mm)
Case Material................................................Black Coated Copper with
Non-Conductive Base
NOTE:
1. Measured From High Line to Low Line
2. Measured From Full Load to 1/4 Load
TRIPLE OUTPUT LOADING TABLE
(1)
Output
( Pin No.)
Voltage
Min.(2)
+5
+12 or -12
+15 or -15
+12 & -5
0.25
0.10
0.10
0.10/0.10
Amperes
Nom.
1.5
0.31
0.25
0.31/0.50
MODEL
NUMBER
EC2EE01
EC2EE02
EC2EE03
EC2EE04
EC2EE05
EC2EE06
EC2EE07
EC2EE08
EC2EE11
EC2EE12
EC2EE13
EC2EE14
EC2EE15
EC2EE16
EC2EE17
EC2EE18
EC2EE21
EC2EE22
EC2EE23
EC2EE24
EC2EE25
EC2EE26
EC2EE27
EC2EE28
INPUT
VOLTAGE
OUTPUT
VOLTAGE
5 VDC
12 VDC
15 VDC
OUTPUT
CURRENT
3000 mA
1250 mA
1000 mA
±625 mA
±500 mA
1500/±310 mA
1500/±250 mA
1500/310/500 mA
3000 mA
1250 mA
1000 mA
±625 mA
±500 mA
1500/±310 mA
1500/±250 mA
1500/310/500 mA
3000 mA
1250 mA
1000 mA
±625 mA
±500 mA
1500/±310 mA
1500/±250 mA
1500/310/500 mA
INPUT CURRENT
NO LOAD
FULL LOAD
20 mA
20 mA
20 mA
35 mA
35 mA
30 mA
30 mA
30 mA
25 mA
25 mA
25 mA
25 mA
25 mA
25 mA
25 mA
25 mA
10 mA
10 mA
10 mA
15 mA
15 mA
15 mA
15 mA
15 mA
1700 mA
1600 mA
1600 mA
1520 mA
1520 mA
1600 mA
1600 mA
1470 mA
810 mA
780 mA
780 mA
750 mA
750 mA
780 mA
780 mA
715 mA
410 mA
390 mA
390 mA
380 mA
380 mA
380 mA
380 mA
350 mA
% EFF.
CASE
6
3&5
3&5
3&5
NOTE:
77
78
78
82
82
78
78
78
77
80
80
84
84
80
80
80
77
80
80
82
82
82
82
82
E
E
E
1. Maximum total power from all outputs is limited to 15 watts but no output should be
allowed to exceed its maximum current.
2. Minimum current on each output is required to maintain specified regulation.
9-18 VDC
±12 VDC
±15 VDC
5/±12 VDC
5/±15 VDC
+5/+12/-5 VDC
5 VDC
12 VDC
15 VDC
CASE E
All Dimensions In Inches(mm)
Tolerance .xx= ±.04, .xxx= ±.010
PIN CONNECTION
Pin
Single Output
Daul Output
Triple Output
+Input
-Input
+Output
Common
-Output
+5V Output
No Pin
0.80
(20.3)
0.20
(5.1)
0.70
(17.8)
0.40
(10.2)
0.30
(7.6)
18-36 VDC
±12 VDC
±15 VDC
5/±12 VDC
5/±15 VDC
+5/+12/-5 VDC
5 VDC
12 VDC
15 VDC
7
6
5
4
3
0.04
(1.0)
DIA
1.
2.
3.
4.
5.
6.
7.
8.
+Input
+Input
-Input
-Input
+Output
No Pin
Common
Output Trim
-Output
No Pin
No Pin
+Output
No Pin
-Output
Remote On/Off Control
Remote On/Off Control
BOTTOM
VIEW
2.50 3.00
(63.5) (76.2)
Logic Compatibility
EC-On
EC-Off
Shutdown Idle Current
Input Resistance
Control Common
CMOS or Open Collector TTL
>+5.5VDC or Open Circuit
<1.8 VDC
10 mA
100K ohms (Ein 0 VDC to 9 VDC)
Referenced to Input Minus
36-72 VDC
±12 VDC
±15 VDC
5/±12 VDC
5/±15 VDC
+5/+12/-5 VDC
External Output Trimming
2
1
8
Output may optionally be externally trimmed (±10%) with a fixed
resistor or an external trimpot as shown.
PIN 7
PIN 7
0.22
(5.6)
min.
0.83
(21.1)
TRIM
UP
RT 1
OR
RT 2
TRIM
DOWN
0.40
(10.2)
1.50
(38.1)
2.56
(65.0)
0.60
(15.2)
NOTE: 1. Nominal Input Voltage 12, 24 or 48 VDC
PIN 4
PIN 4
PIN 4
10K ohms
TRIMPOT
59
PIN 6
PIN 6
60
All Specifications Typical At Nominal Line, Full Load and 25˚C Unless Otherwise Noted.
EC2EE
EC2EE
OUTPUT SPECIFICATIONS:
Voltage Accuracy
Single Output........................................................................................................................................................................................................................±1.0% max.
Dual +Output........................................................................................................................................................................................................................±1.0% max.
-Output.........................................................................................................................................................................................................................±3.0% max.
Triple, 5V.................................................................................................................................................................................................................................±2.0% max.
12V/15V.......................................................................................................................................................................................................................±3.0% max.
Voltage Balance (Dual).......................................................................................................................................................................................................±1.0% max.
Transient Response:
Single, 25% Step Load Change...........................................................................................................................................................................................<500µ sec.
Dual, FL-1/2L±1% Error Band.................................................................................................................................................................................................<500µ sec.
External Trim Adj. Range...............................................................................................................................................................................................................±10%.
Ripple & Noise, 20MHz BW.........................................................................................................................................................................................10mV RMS, max.
75mV p-p max.
Temperature Coefficient.....................................................................................................................................................................................................± 0.02%/°C
Short Circuit Protection......................................................................................................................................................................................................Continuous
Line Regulation
1
, Single/Dual..............................................................................................................................................................................................±0.2% max.
Triple.....................................................................................................................................................................................................±1.0% max.
Load Regulation
2
, Single/Dual............................................................................................................................................................................................±1.0% max.
Triple.....................................................................................................................................................................................................±5.0% max.
