Daattaasshheeeett
BD7xxL5FP-C
●Absolute Maximum Ratings（Ta=25℃）
Parameter
Symbol
VCC
Pd
Ratings
-0.3 to +50.0
1.2
Unit
V
*1
Supply Voltage
*2
Power Dissipation
W
Operating Temperature Range
Storage Temperature Range
Topr
-40 to +125
-55 to +150
150
°C
°C
°C
Tstg
Maximum Junction Temperature
Tjmax
*1 Pd should not be exceeded.
*2 9.6mW/℃ reduction when Ta≧25℃ if mounted on a glass epoxy board of 70mm×70mm×1.6mm.
●Operating Conditions（-40 < Ta < +125℃）
■BD733L5FP-C
Parameter
Supply Voltage
Symbol
VCC
Min.
4.17
3.0
0
Max.
45.0
-
Unit
*3
*4
V
V
Startup Voltage
Output Current
VCC
IOUT
500
mA
■BD750L5FP-C
Parameter
Symbol
VCC
Min.
5.6
3.0
0
Max.
45.0
-
Unit
V
*3
*4
Supply Voltage
Startup Voltage
Output Current
VCC
V
IOUT
500
mA
*3 For output voltage, refer to the dropout voltage corresponding to the output current. This condition is 200mA load.
*4 When IOUT=0mA
●Electrical Characteristics (BD733L5FP-C)
（Unless otherwise specified ,-40 < Ta < +125°C,VCC=13.5V, IOUT=0mA, Reference value: Ta=25°C）
Limit
Parameter
Quiescent current
Symbol
Ib
Unit
Conditions
Min.
-
Typ.
6
Max.
15
μA
V
8V<VCC<16V
0mA<IOUT<500mA
3.23
-
3.30
0.4
3.37
0.8
Output voltage
Dropout voltage
Ripple rejection
VOUT
ΔVd
V
VCC=VOUT×0.95, IOUT=200mA
f=120Hz, ein=1Vrms,
IOUT=100mA
R.R.
50
63
-
dB
Line regulation
Load regulation
Reg I
-
-
5
5
20
20
mV 8V<VCC<16V
Reg L
mV 10mA<IOUT<250mA
●Electrical Characteristics (BD750L5FP-C)
（Unless otherwise specified ,-40 < Ta < +125°C,VCC=13.5V, IOUT=0mA, Reference value: Ta=25°C）
Limit
Parameter
Quiescent current
Symbol
Ib
Unit
Conditions
Min.
-
Typ.
6
Max.
15
μA
V
8V<VCC<16V
0mA<IOUT<500mA
5.0
5.1
0.5
Output voltage
Dropout voltage
Ripple rejection
VOUT
ΔVd
4.9
-
0.25
V
VCC=VOUT×0.95, IOUT=200mA
f=120Hz, ein=1Vrms,
IOUT=100mA
R.R.
50
60
-
dB
Line regulation
Load regulation
Reg I
-
-
5
5
20
20
mV 8V<VCC<16V
Reg L
mV 10mA<IOUT<250mA
