ABSOLUTE MAXIMUM RATINGS
Symbol
Item
Rating
12
Unit
V
VIN
Input Voltage
Output Voltage
Output Current
VOUT
IOUT
V
−0.3 to VIN+0.3
150
mA
Power Dissipation∗ (SOT-23-5)
Power Dissipation∗ (SOT-89)
Power Dissipation∗ (TO-92) (Discontinued)
Operating Temperature Range
Storage Temperature Range
420
PD
mW
900
300
Topt
Tstg
−40 to 85
−55 to 125
°C
°C
Tsolder
Lead Temperature (Soldering)
260°C,10s
∗) For Power Dissipation, please refer to PACKAGE INFORMATION.
ABSOLUTE MAXIMUM RATINGS
Electronic and mechanical stress momentarily exceeded absolute maximum ratings may cause the
permanent damages and may degrade the life time and safety for both device and system using the device
in the field.
The functional operation at or over these absolute maximum ratings is not assured.
RECOMMENDED OPERATING CONDITIONS (ELECTRICAL CHARACTERISTICS)
All of electronic equipment should be designed that the mounted semiconductor devices operate within the
recommended operating conditions. The semiconductor devices cannot operate normally over the
recommended operating conditions, even if when they are used over such conditions by momentary
electronic noise or surge. And the semiconductor devices may receive serious damage when they continue
to operate over the recommended operating conditions.
4
RICOH [ RICOH ELECTRONICS DEVICES DIVISION ]
