R3130N×××A/C, R3131N×××A/C
• R3131N46××5-TR
[Topt=25°C]
Symbol
Item
Conditions
MIN.
TYP.
MAX.
Unit
VDDH
Maximum Operating Voltage
6.0
V
CMOS Output
IOH=-10µA
VDS=6.5V
VDDL (*3) Minimum Operating Voltage
0.90
1.00
V
Nch Open Drain
Output
VDET
ISS1
Detector Threshold
Supply Current1
Supply Current2
Supply Current3
“H” Output Voltage
“L” Output Voltage
4.581
4.650
1.40
1.30
1.15
4.719
5.00
4.00
3.50
V
µA
µA
µA
V
VDD=6.00V
VDD=4.75V
VDD=4.55V
ISS2
ISS3
VOH
VOL
VDD=4.55V, IOUT=-800µA
VDD=4.75V, IOUT=3.2mA
0.8×VDD 0.95×VDD
0.18
0.40
V
Tdelay Output Delay Time for
Refer to electrical characteristics by Output Delay Time for release
(*2)
release
∆VDET/
∆Topt
Detector Threshold
ppm/
°C
-40°C ≤ Topt ≤ 85°C
±100
Temperature Coefficient
*1) Supply Voltage when Output Voltage becomes equal or less than 0.3V. (As for Nch Open Drain Output
type, pull-up resistor is 470kΩ, pull-up voltage is 5.0V.
*2) Time interval of rising edge of VDD which is set from 1.0V to VDET+1.0V, and the point of which Output volt-
age reaches to 50% of final voltage.
*3) CMOS Output type; Supply Voltage when Output Voltage becomes equal or more than 0.8×VDD.
Nch Open Drain type; Supply Voltage when off leakage current becomes equal or less than 0.1µA.
12
RICOH [ RICOH ELECTRONICS DEVICES DIVISION ]
