Preliminary
RT9012
Outline Dimension
D2
D
L
E
E2
SEE DETAIL A
1
e
b
2
1
2
1
A
A3
DETAILA
Pin #1 ID and Tie Bar Mark Options
A1
Note : The configuration of the Pin #1 identifier is optional,
but must be located within the zone indicated.
Dimensions In Millimeters
Dimensions In Inches
Symbol
Min
Max
Min
Max
A
A1
A3
b
0.700
0.000
0.175
0.200
1.950
1.000
1.950
0.400
0.800
0.050
0.250
0.300
2.050
1.250
2.050
0.650
0.028
0.000
0.007
0.008
0.077
0.039
0.077
0.016
0.031
0.002
0.010
0.012
0.081
0.049
0.081
0.026
D
D2
E
E2
e
0.500
0.020
L
0.300
0.400
0.012
0.016
W-Type 8L DFN 2x2 Package
Richtek Technology Corporation
Headquarter
Richtek Technology Corporation
Taipei Office (Marketing)
5F, No. 20, Taiyuen Street, Chupei City
Hsinchu, Taiwan, R.O.C.
8F, No. 137, Lane 235, Paochiao Road, Hsintien City
Taipei County, Taiwan, R.O.C.
Tel: (8863)5526789 Fax: (8863)5526611
Tel: (8862)89191466 Fax: (8862)89191465
Email: marketing@richtek.com
DS9012-06 August 2007
www.richtek.com
11
