Smart Com Radio Transceiver IC
Application Circuit
RF600T
The circuit shown below is for a typical RF600T application. A 9 way ‘D’ connector provides an RS232
termination to the host system and the RXQ1 hybrid contains all of the circuitry required to implement the
RF path. In many applications it will be possible to dispense with the option links and hard-wire the options
to the desired settings. Note however that the host and RF baud options and loop option must be set using
resistors as described above.
RF600T Application Circuit with RXQ1 Transceiver and RS232 Interface.
DS601-4
25 JUN 2004
th
©2004 Reg. No. 227 4001, ENGLAND
Page 8
