MITSUBISHI MICROCOMPUTERS
M37905F8CFP, M37905F8CSP
16-BIT CMOS MICROCOMPUTER
Address (Hexadecimel notation)
Address (Hexadecimel notation)
Reserved area (Note)
Reserved area (Note)
Reserved area (Note)
Port P1 register
00000016
00000116
00000216
00000316
00004016 Count start register 0
00004116 Count start register 1
00004216 One-shot start register 0
One-shot start register 1
Up-down register 0
Timer A clock division select register
00004316
00004416
00004516
00004616
00004716
00004816
00004916
00004A16
00004B16
00004C16
00004D16
00004E16
00004F16
00005016
00005116
00005216
00005316
00005416
00005516
00005616
00000416 Reserved area (Note)
00000516 Port P1 direction register
00000616 Port P2 register
00000716 Reserved area (Note)
00000816 Port P2 direction register
00000916 Reserved area (Note)
00000A16 Port P4 register
00000B16 Port P5 register
00000C16 Port P4 direction register
00000D16 Port P5 direction register
00000E16 Port P6 register
00000F16 Port P7 register
00001016 Port P6 direction register
00001116 Port P7 direction register
00001216 Port P8 register
00001316
Timer A0 register
Timer A1 register
Timer A2 register
Timer A3 register
Timer A4 register
Timer B0 register
Timer B1 register
00001416 Port P8 direction register
00001516
Timer B2 register
Reserved area (Note)
Reserved area (Note)
Reserved area (Note)
Reserved area (Note)
Timer A0 mode register
00001616
00001716
00001816
00001916
00001A16
00001B16
00001C16
00001D16
00005716 Timer A1 mode register
00005816 Timer A2 mode register
00005916 Timer A3 mode register
00005A16 Timer A4 mode register
00005B16 Timer B0 mode register
00005C16 Timer B1 mode register
00005D16 Timer B2 mode register
Processor mode register 0
Processor mode register 1
00001E16 A-D control register 0
00001F16 A-D control register 1
00005E16
00005F16
00002016
00006016 Watchdog timer register
A-D register 0
00002116
Watchdog timer frequency select register
00006116
00002216
00006216 Particular function select register 0
00006316 Particular function select register 1
A-D register 1
00002316
00002416
00006416
00006516
Particular function select register 2
Reserved area (Note)
A-D register 2
00002516
00002616
00006616 Debug control register 0
00006716 Debug control register 1
00006816
00006916 Address comparison register 0
00006A16
A-D register 3
00002716
00002816
A-D register 4
00002916
00002A16
00002B16
A-D register 5
00006B16
Address comparison register 1
00002C16
00002D16
00002E16
00002F16
00006C16
00006D16
00006E16
00006F16
A-D register 6
3 interrupt control register
4 interrupt control register
INT
INT
A-D register 7
00003016 UART0 transmit/receive mode register
00003116 UART0 band rate register (BRG0)
00007016 A-D conversion interrupt control register
00007116 UART0 transmit interrupt control register
00007216 UART0 receive interrupt control register
00007316 UART1 transmit interrupt control register
00007416 UART1 receive interrupt control register
00007516 Timer A0 interrupt control register
00007616 Timer A1 interrupt control register
00007716 Timer A2 interrupt control register
00007816 Timer A3 interrupt control register
00007916 Timer A4 interrupt control register
00007A16 Timer B0 interrupt control register
00007B16 Timer B1 interrupt control register
00007C16 Timer B2 interrupt control register
00003216
UART0 transmit buffer register
00003316
00003416 UART0 transmit/receive control register 0
00003516 UART0 transmit/receive control register 1
00003616
UART0 receive buffer register
00003716
00003816 UART1 transmit/receive mode register
00003916 UART1 baud rate register (BRG1)
00003A16
UART1 transmit buffer register
00003B16
00003C16 UART1 transmit/receive control register 0
00003D16 UART1 transmit/receive control register 1
00007D16
00007E16
00007F16 INT
0 interrupt control register
1 interrupt control register
2 interrupt control register
INT
INT
00003E16
UART1 receive buffer register
00003F16
Note: Do not write to this address.
Fig. 2 Location of SFRs (1)
