Notes
1. 1.1/10 Duty cycle, pulse width 10ms.
2. The above forward voltage measurement allowance tolerance is± 0.3V.
3. The above color coordinates measurement allowance tolerance is 0.005.
4. The above luminous intensity measurement allowance tolerance ±10%.
5. Care is to be taken that power dissipation does not exceed the absolute maximum rating of the product.
6. All measurements were made under the standardized environment of Refond.
7.When the LEDs are in operation the maximum current should be decided after measuring the package
temperature，junction temperature should not exceed the maximum rate
8. ESD yield is over 90% at 2000V ESD (HBM). ESD protection during products handing is needed.
9. Tj refers to the highest temperature chip PN junction temperature in COB, which is usually the chip PN
junction temperature in the luminescence center.
