TOP252-262
Conditions
SOURCE = 0 V; TJ = -40 to 125 °C
Parameter
Symbol
Min
Typ
Max
Units
(Unless Otherwise Specified)
Output (cont.)
TJ = 25 °C
TJ = 100 °C
TJ = 25 °C
TJ = 100 °C
TJ = 25 °C
TJ = 100 °C
TJ = 25 °C
TJ = 100 °C
1.45
2.25
1.20
1.80
1.05
1.55
0.90
1.35
1.70
2.60
1.40
2.10
1.20
1.80
1.05
1.55
TOP259
ID = 600 mA
TOP260
ID = 700 mA
ON-State
Resistance
RDS(ON)
Ω
TOP261
ID = 800 mA
TOP262
ID = 900 mA
TJ ≤ 85 °C, See Note E
18
36
DRAIN Supply Voltage
V
OFF-State Drain
Leakage Current
VV, VM = Floating, IC = 4 mA,
DS = 560 V, TJ = 125 °C
IDSS
470
μA
V
VV, VM = Floating, IC = 4 mA,
TJ = 25 °C
Breakdown
Voltage
BVDSS
700
V
See Note F
Rise Time
Fall Time
tR
tF
100
50
ns
ns
Measured in a Typical Flyback
Converter Application
Supply Voltage Characteristics
TOP252-255
0.6
0.9
1.1
0.8
1.1
1.5
1.2
1.4
1.6
1.3
1.6
2.2
2.0
2.3
2.5
2.2
2.5
2.9
66 kHz
Operation
Output
MOSFET
Enabled
VX, VV, VM =
0 V
TOP256-258
TOP259-262
TOP252-255
TOP256-258
TOP259-262
ICD1
Control Supply/
Discharge Current
mA
132 kHz
Operation
Output MOSFET Disabled
VX, VV, VM = 0 V
ICD2
0.3
0.6
1.3
