PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 076BH: RXSDQ FIFO Indirect Cells and Packets Count
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Unused
Unused
Unused
Unused
Unused
Bit 8
Unused
Bit 7
Unused
Bit 6
Unused
Bit 5
Unused
Bit 4
Unused
Bit 3
Bit 2
Bit 1
Bit 0
R
R
R
R
COUNT[3]
COUNT[2]
COUNT[1]
COUNT[0]
COUNT[3:0]:
These read-only bits hold the last sampled count for the FIFO requested for in the RXSDQ
FIFO Indirect Address register’s PHYID[5:0] bits. This register is latched when register
0000H is written to for a global performance monitor update. After the count is latched into
the register, the internal counter is reset to 0, and starts counting again. When this counter
reaches it’s maximum count, it rolls over. This register is for internal diagnostics only.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
346
