PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 074EH: RCFP Receive Minimum Length Packet Error Counter
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
RMINL[15]
RMINL[14]
RMINL[13]
RMINL[12]
RMINL[11]
RMINL[10]
RMINL[9]
RMINL[8]
RMINL[7]
RMINL[6]
RMINL[5]
RMINL[4]
RMINL[3]
RMINL[2]
RMINL[1]
RMINL[0]
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
RMINL[15:0]:
When POS mode is selected, the RMINL[15:0] bits indicate the number of minimum length
packet errors received during the last accumulation interval. This counter is held at value 0
when ATM mode is selected.
A write to any one of the RCFP performance monitor registers loads the registers with the
current counter value and resets the internal counter to 1 or 0. The counter reset value is
dependent on if there was a count event during the transfer of the count to the Receive
Minimum Length Packet Counter registers. The counter should be polled regularly to avoid
saturating.
To allow for synchronization update with all other blocks, register 0000H can be written to
initiate a global performance counter update.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
323
