PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0744H: RCFP Maximum Packet Length
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
MAXPL[16]
MAXPL[15]
MAXPL[14]
MAXPL[13]
MAXPL[12]
MAXPL[11]
MAXPL[10]
MAXPL[9]
MAXPL[8]
MAXPL[7]
MAXPL[6]
MAXPL[5]
MAXPL[4]
MAXPL[3]
MAXPL[2]
MAXPL[1]
0
0
0
0
0
0
1
1
0
0
0
0
0
0
0
0
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
MAXPL[16:1]:
The Maximum Packet Length (MAXPL[16:0]) bits are used to set the maximum packet length.
MAXPL[0] is automatically set to logic 0. Packets larger than this length are marked with an
error. This Maximum Packet Length defaults to 1.5 Kbytes. The packet length used here is
defined as the number of bytes encapsulated into the POS frame excluding byte stuffing but
including the FCS. The default maximum packet length is 1536 octets. The maximum packet
length allowed is 128 Kbytes.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
315
