PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0741H: RCFP Interrupt Enable
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
Unused
Unused
Unused
Unused
OOFV
X
X
X
X
X
X
X
X
0
0
0
0
0
0
0
0
R
Bit 8
R
LOFV
Bit 7
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
MINLE
MAXLE
ABRTE
XFERE
CCRCE
UCRCE
OOFE
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
LOFE
LOFE:
The LOFE bit enables the generation of an interrupt due to a change in the ATM LCD state.
When LOFE is set to logic 1, the interrupt is enabled.
OOFE:
The OOFE bit enables the generation of an interrupt due to a change in ATM cell delineation
state or packet Idle state. When OOFE is set to logic 1, the interrupt is enabled.
UCRCE
The UCRCE bit enables the generation of an interrupt due to the detection of an
uncorrectable ATM HCS or packet FCS error. When UCRCE is set to logic 1, the interrupt is
enabled.
Reserved:
The Reserved bit should be set to logic 0 for proper operation.
XFERE:
The XFERE bit enables the generation of an interrupt when an accumulation interval is
completed and new values are stored in the RCFP performance monitor counter holding
registers. When XFERE is set to logic 1, the interrupt is enabled.
