PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Indirect Register 00H: RTTP PATH Trace Configuration
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
ZEROEN
PER5
Bit 8
Bit 7
Bit 6
Bit 5
R/W
R/W
R/W
R/W
R/W
R/W
0
0
0
0
0
0
Bit 4
Bit 3
NOSYNC
LENGTH16
ALGO[1]
ALGO[0]
Bit 2
Bit 1
Bit 0
ALGO[1:0]:
The tail trace algorithm select (ALGO[1:0]) bits select the algorithm used to process the tail
trace message.
ALGO[1:0]
Tail trace algorithm
Algorithm disable
Algorithm 1
00
01
10
11
Algorithm 2
Algorithm 3
When ALGO[1:0] is set to logic 00b, the tail trace algorithms are disable. The corresponding
TIUV, TIMV register bits and the corresponding TIU, TIM output signal time slots are set to
logic 0.
LENGTH16:
The message length (LENGTH16) bit selects the length of the tail trace message use by
algorithm 1 and algorithm 2. When LENGTH16 is set to logic 1, the length of the tail trace
message is 16 byte. When LENGTH16 is set to logic 0, the length of the tail trace message
is 64 byte.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
280
