PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0703H: RTTP PATH Trace Unstable Interrupt Enable
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
Unused
Unused
Reserve
Reserve
Reserve
Reserve
Reserve
Reserve
Reserve
Reserve
Reserve
Reserve
Reserve
TIUE[1]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
0
0
0
0
0
0
0
0
0
0
0
0
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
TIUE[1]:
The trace identifier unstable interrupt enable (TIUE[1]) bit controls the activation of the
interrupt (INTB) output. When the bit is set to logic 1, the corresponding pending interrupt will
assert the interrupt (INTB) output. When the bit is set to logic 0, the corresponding pending
interrupt will not assert the interrupt (INTB) output.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
275
