PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Indirect Register 02H: RSVCA Positive Justifications Performance Monitor
Bit
Type
Function
Unused
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
R
R
R
R
R
R
R
R
R
R
R
R
R
PJPMON[12]
PJPMON[11]
PJPMON[10]
PJPMON[9]
PJPMON[8]
PJPMON[7]
PJPMON[6]
PJPMON[5]
PJPMON[4]
PJPMON[3]
PJPMON[2]
PJPMON[1]
PJPMON[0]
0
0
0
0
0
0
0
0
0
0
0
0
0
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
PJPMON[12:0]:
This register reports the number of positive pointer justification events that occurred on the
outgoing side in the previous accumulation interval. The content of this register becomes
valid a maximum of 3 TCLK cycles after a transfer is triggered by writing a logic one to the
PMONXFER bit of the SVCA Diagnostic/Configuration Register or by writing to the S/UNI-
2488 Identity, and Global Performance Monitor Update register.
