PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0604H: RSVCA Negative Justification Interrupt Status
Bit
Type
Function
Reserved[3]
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
R/W
R/W
R/W
R/W
R
X
X
X
X
0
0
0
0
0
0
0
0
0
0
0
0
Reserved[2]
Reserved[1]
Reserved[0]
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
NPJI[1]
R
R
Bit 8
R
Bit 7
R
Bit 6
R
Bit 5
R
Bit 4
R
Bit 3
R
Bit 2
R
Bit 1
R
Bit 0
R
NPJI[1]:
The negative pointer justification interrupt status (NPJI[1]) bit indicates a negative pointer
adjustment in the STS-48c/STM-4-4c stream. NPJI[1] is set to logic 1 to indicate a negative
pointer justification event in the outgoing data stream. This interrupt status bit is independent
of the interrupt enable bit. NPJI[1] is cleared to logic 0 when this register is read.
