S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x005, 0x105, 0x205, 0x305, 0x405, 0x505, 0x605, 0x705:
Channel Master Configuration #2
Bit
Type
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Function
SLLE
SDLE
LOOPT
DPLE
AUTOLRDI
AUTOPRDI
AUTOLFEBE
AUTOPFEBE
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
0
0
0
1
1
1
1
For more details refer to the Operation Section of this document.
AUTOPFEBE
The AUTOPFEBE bit determines if the remote path block errors are sent upon detection of
an incoming path BIP error event. When AUTOPFEBE is set to logic one, one path FEBE
is inserted for each path BIP error event, respectively. When AUTOPFEBE is set to logic
zero, incoming path BIP error events do not generate FEBE events.
AUTOLFEBE
The AUTOLFEBE bit determines if remote line block errors are sent upon detection of an
incoming line BIP error event. When AUTOLFEBE is set to logic one, one line FEBE is
inserted for each line BIP error event, respectively. When AUTOLFEBE is set to logic zero,
incoming line BIP error events do not generate FEBE events.
AUTOPRDI
The AUTOPRDI bit determines whether STS path remote defect indication (RDI) is sent
immediately upon detection of an incoming alarm. When AUTOPRDI is set to logic one,
STS path RDI is inserted immediately upon declaration of several alarms. Each alarm can
individually be enabled and disabled using the channel’s Path RDI Control Registers.
AUTOLRDI
The AUTOLRDI bit determines if line remote defect indication (RDI) is sent immediately
upon detection of an incoming alarm. When AUTOLRDI is set to logic one, line RDI is
inserted immediately upon declaration of several alarms. Each alarm can individually be
enabled and disabled using the channel’s Line RDI Control Registers.
Proprietary and Confidential to PMC-Sierra, Inc., and for its customers’ internal use.
Document No.: PMC- 2010299, Issue 2
120
