PM5365 TEMAP
DATASHEET
PMC-1991148
ISSUE 3
HIGH DENSITY VT/TU MAPPER
AND M13 MULTIPLEXER
Address
Register
0B18H-
0B37H
Reserved
0B38H
0B39H
0B3AH
0B3BH
0B3CH
0B3DH
0B3EH
0B3FH
PMON Interrupt Enable/Status
PMON Framing Bit Error Count
PMON OOF/COFA/Far End Block Error Count (LSB)
PMON OOF/COFA/Far End Block Error Count (MSB)
PMON Bit Error/CRCE Count (LSB)
PMON Bit Error/CRCE Count (MSB)
PMON Reserved
PMON Reserved
0B40H-
0B4FH
Reserved
0B50H
0B51H
0B52H
0B53H
0B54H
0B55H
0B56H
0B57H
PRBS Generator/Checker Control
PRBS Checker Interrupt Enable/Status
PRBS Pattern Select
PRBS Reserved
PRBS Error Count Register #1
PRBS Error Count Register #2
PRBS Error Count Register #3
PRBS Reserved
0B58H-
0B5FH
Reserved
0B60H
0B61H
0B62H
0B63H
T1 ALMI Configuration
T1 ALMI Interrupt Enable
T1 ALMI Interrupt Status
T1 ALMI Alarm Detection Status
Reserved
0B64H-
0B6BH
0B6CH
0B6DH
T1 FRMR Configuration
T1 FRMR Interrupt Enable
