PixArt Imaging Inc.
Track-on-Glass Laser Sensor
Conꢀguration_I
Address: 0x0F
Access: R/W
Reset Value: 0x0a
Bit
Field
7
6
5
4
3
2
1
0
Reserved
Reserved
Reserved Reserved
RES3
RES2
RES1
RES0
Data Type: Bit Field
USAGE:
This register sets the resolution.
Field Name
Description
RES[3:0]
Sets resolution
0x04 = 400
0x06 = 600
0x08 = 800
0x09 = 1000
0x0a =1100
0x0b =1200
0x0c =1300
0x0d =1400
0x0e =1500
0x0f =1600
