Bus system cable - SAC-5PY-F/2X15,0-920-MS-FS - 1436071
Technical data
Cable
Twisted pairs
2 cores to the pair
Type of pair shielding
Overall twist
Plastic-coated aluminum foil, aluminum side outside
2 pairs around a drain wire in the center to the core
Tinned copper braided shield
80 %
Shielding
Optical shield covering
External sheath, color
External cable diameter D
Minimum bending radius, fixed installation
Minimum bending radius, flexible installation
Number of bending cycles
Bending radius
violet RAL 4001
6.7 mm ±0,3 mm
5 x D
10 x D
5000000
70 mm
Minimum bending radius, drag chain applications
Traversing path
10 x D
4.5 m
Traversing rate
3 m/s
Acceleration
3 m/s²
Cable weight
90 kg/km
Outer sheath, material
Material conductor insulation
PUR
Foamed PE (Data cable)
PE (Power supply)
Conductor material
Insulation resistance
Tin-plated Cu litz wires
≥ 5 GΩ*km (Data cable)
≥ 5 GΩ*km (Power supply)
≤ 181.80 Ω/km (Data cable)
≤ 114.80 Ω/km (Power supply)
nom. 40 nF/km (Data cable)
120 Ω ±10 % (with 1 MHz)
≤ 22.9 dB/km (with 1 MHz)
≤ 16.4 dB/km (At 500 kHz)
≤ 9.5 dB/km (At 125 kHz)
≤ 300 V (Peak value, not for high-power applications)
2000 V (50 Hz, 1 min.)
2000 V (50 Hz, 1 min.)
UL 1581, Sec. 1060 (FT-1)
IEC 60332-1
Loop resistance
Cable capacity
Wave impedance
Attenuation
Nominal voltage, cable
Test voltage Core/Core
Test voltage Core/Shield
Flame resistance
in accordance with ISO 6722-1 5.22 (UN ECE-R 118.01)
in accordance with DIN VDE 0472 part 815
according to IEC 60754-1
Low adhesion
Halogen-free
Other resistance
Ambient temperature (operation)
-40 °C ... 80 °C (cable, fixed installation)
-20 °C ... 80 °C (cable, flexible installation)
