 浏览型号0442079的Datasheet PDF文件第2页浏览型号0442079的Datasheet PDF文件第3页浏览型号0442079的Datasheet PDF文件第4页浏览型号0442079的Datasheet PDF文件第5页浏览型号0442079的Datasheet PDF文件第6页浏览型号0442079的Datasheet PDF文件第7页浏览型号0442079的Datasheet PDF文件第8页
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in
the user's documentation. Our General Terms of Use for Downloads are valid
(http://download.phoenixcontact.com)
Ground modular terminal block, Connection method: Screw connection, Cross section: 0.2 mm² - 10
mm², AWG 24 - 8, Width: 8.2 mm, Color: green-yellow, Mounting type: NS 35/7.5, NS 35/15, NS 32
Product description
Ground modular terminal block, Connection method: Screw connection, Cross section: 0.2 mm² - 10 mm², AWG 24 - 8, Width: 8.2 mm,
Color: green-yellow, Mounting type: NS 35/7.5, NS 35/15, NS 32

Key commercial data
Packing unit
Minimum order quantity
Catalog page
GTIN
Weight per piece (including packing)
Weight per Piece (excluding packing)
Country of origin
0.0 GRM
27.05 GRM
CHINA
1
50
Page 411 (CL1-2011)
Technical data
General
Number of levels
Number of connections
Color
Insulating material
Inflammability class according to UL 94
1
2
green-yellow
PA
V0
Dimensions
Width
Length
Height NS 35/7.5
Height NS 35/15
Height NS 32
8.2 mm
42.5 mm
47 mm
54.5 mm
52 mm
14.05.2012   Page 1 / 8
