Philips Semiconductors
Product specification
FM radio circuit
TDA7000
RATINGS
Limiting values in accordance with the Absolute Maximum System (IEC 134)
Supply voltage (pin 5)
V
V
max.
12 V
P
Oscillator voltage (pin 6)
V −0,5 to V + 0,5 V
P P
6-5
Total power dissipation
see derating curve Fig.2
Storage temperature range
Operating ambient temperature range
T
T
−55 to +150 °C
0 to + 60 °C
stg
amb
Fig.2 Power derating curve.
D.C. CHARACTERISTICS
V = 4,5 V; T
= 25 °C; measured in Fig.4; unless otherwise specified
amb
P
PARAMETER
SYMBOL
MIN.
TYP.
4,5
MAX.
UNIT
Supply voltage (pin 5)
Supply current
V
2,7
10
V
P
at V = 4,5 V
I
I
−
−
−
−
−
8
−
−
−
−
−
mA
µA
V
P
P
Oscillator current (pin 6)
Voltage at pin 14
280
1,35
60
6
V
14-16
Output current at pin 2
I
µA
V
2
Voltage at pin 2; R = 22 kΩ
V
1,3
L
2-16
May 1992
4
