maximum peak temperature
= MSL limit, damage level
temperature
minimum peak temperature
= minimum soldering temperature
peak
temperature
time
001aac844
MSL: Moisture Sensitivity Level
Fig 29. Temperature profiles for large and small components
For further information on temperature profiles, refer to Application Note AN10365
“Surface mount reflow soldering description”.
17. Abbreviations
Table 9.
Abbreviations
Description
Acronym
CDM
CMOS
ESD
Charged-Device Model
Complementary Metal-Oxide Semiconductor
ElectroStatic Discharge
GPIO
HBM
LED
General Purpose Input/Output
Human Body Model
Light Emitting Diode
ID
Identification
LSB
Least Significant Bit
MSB
PLC
Most Significant Bit
Programmable Logic Controller
Redundant Array of Independent Disks
RAID
PCA9675
