Outdoor unit
Function
Single VGA
(variable-
gain
amplifier)
Function
MPA
(medium
power
amplifier)
Function
Buffer
Product
MMIC
Gain range
31 dB
Package
P
L
(1dB)
@ 940 MHz
24 dBm
28 dBm
25 dBm
28 dBm
30 dBm
Type
Function
Dual VGA
(variable-
gain
amplifier)
Function
PLL + VCO
(LO
generator)
Function
Product
MMIC
28 dB
Product
MMIC
Noise
-131 dBc/Hz @
1 MHz offset
@ 5.3 GHz
Package
Gain range
24 dB
Type
BGX7300*
Package
Type
Product
Package
Type
Type
Type
Type
MMIC
Product
Wideband
transistor
Package
Product
RF transistor
SiGe:C
transistor
Package
Oscillator
RF transistor
SiGe:C
transistor
Type
Function
LNA
Product
RF transistor
SiGe:C
transistor
Package
* Check status in section 3.1, as this type is not yet released for mass
production
NXP BTS Tx component demonstrator board
Function
Product
Package
IF gain block
IF
MMIC
General-
purpose
wideband
amplifiers
MMIC
Product highlight:
The BGA7350 MMIC is a dual independent digitally controlled IF
variable-gain amplifier (VGA) operating from 50 to 250 MHz. Each IF
VGA amplifies with a gain range of 24 dB and, at its maximum gain
setting, delivers 17 dBm output power at 1 dB gain compression
with superior linear performance. The BGA7350 is optimized for a
differential gain error of less than ±0.1 dB for accurate gain control
and has a total integrated gain error of less than ±0.4 dB. It is housed
in a 32-pin leadless HVQFN package (5 x 5 mm).
`
Dual independent digitally controlled 24 dB gain range VGAs,
with 5-bit control interface
`
50 to 250 MHz frequency operating range
`
Gain step size: 1 dB ± 0.1 dB
`
18.5 dB power gain
`
Fast gain stage switching capability
`
17 dBm output power at 1 dB gain compression
`
5 V single supply operation with power-down control
`
Logic-level shutdown control pin reduces supply current
`
ESD protection at all pins
`
Unconditionally stable
Features
