1.4.4
Cellular receiver
Application diagram
GSM/EDGE FE
GSM/
EDGE
SWITCH
PA
BPF
TRANSCEIVER
duplexer
UMTS
LTE
001aan957
Recommended products
Function
LNA
Product
MMIC
SiGe:C MMIC
Package
Type
Product highlight:
The BGU7003 MMIC is a wideband amplifier in SiGe:C technology for
high-speed, low-noise applications. It is housed in a plastic leadless
6-pin extremely thin small outline SOT886 package.
`
`
`
`
`
`
Features
Applicable between 40 MHz and 6 GHz
LTE LNA: 1 dB NF, 18.5 dB gain and -5 dBm IIP3 at 750 MHz
Integrated temperature-stabilized bias for easy design
Bias current configurable with external resistor
Power-down mode current consumption < 1 μA
ESD protection > 1 kV Human Body Model (HBM) on all pins
28
NXP Semiconductors RF Manual 16
th
edition
