1.3.2
Basic TV tuner
Application diagram
RF input
From antenna,
cable, active splitter,
etc.
MOSFET
V
AGC
IF
bra500
Recommended products
Function
Product
VHF low
Package
Package
Type
Type
Function
Bandswitching
Product
Bandswitch diode
Package
Package
Package
Package
2-in-1 with
band switch
@5V
MOSFET
2-in-1 @ 5 V
5V
Type
Type
Type
Type
BF1217
Input filter
Varicap
diode
VHF high
Function
Product
VHF low
UHF
Bandpass filter
Varicap
diode
VHF high
Function
Product
UHF
5V
Function
Product
VHF low
RF
pre-amplifier
MOSFET
2-in-1 @ 5 V
Oscillator
Varicap
diode
VHF high
UHF
V
Function
Product
RF
pre-amplifier
Product highlight:
with bypass
The BGU7045 MMIC is a 3.3 V wideband amplifier with bypass mode.
It is designed specifically for high-linearity, low-noise applications
over a frequency range of 40 MHz to 1 GHz. It is especially suited
to set-top box applications. The LNA is housed in a 6-pin SOT363
plastic SMD package.
`
`
`
`
`
`
`
Features
Internally biased
Noise figure of 2.8 dB
High linearity with an IP3
O
of 29 dBm
75 Ω input and output impedance
Power-down during bypass mode
Bypass mode current consumption < 5 mA
ESD protection > 2 kV HBM and >1.5 kV CDM on all pins
