Function
Discrete
attenuator
Product
RF diode
PIN diode
Package
Various
Package
Type
BAP64^
Type
BGU7060
Type
Type
Type
Type
BGX7220
BGX7221
Type
BGX7300*
Function
Product
RF transistor
SiGe:C transistor
LNA (low noise
amplifier)
MMIC
SiGe:C MMIC
Function
Single VGA
(variable-gain
amplifier)
Function
Dual VGA
(variable-gain
amplifier)
Function
MPA
(medium
power
amplifier)
Product
MMIC
Gain range
31 dB
Package
Product
MMIC
Gain range
24 dB
28 dB
P
L
(1dB) @ 940 MHz
24 dBm
28 dBm
25 dBm
28 dBm
30 dBm
Frequency
0.7 - 1.2 GHz
1.7 -2.7 GHz
Noise
131 dBc/Hz @ 1 MHz
offset @ 5.3 GHz
Output power
0 dBm
4 dBm
Package
Product
Package
MMIC
Function
Dual mixer
Product
MMIC
Package
Function
Product
PLL + VCO
MMIC
(LO generator)
Function
IQ modulator
Product
MMIC
Package
Package
Type
BGX7100
BGX7101
* Check status in section 3.1, as this type is not yet released for mass production
for mass production
^ SOD523, SOD323, SOT23 & SOT323
Product highlight:
Digital VGAs BGA7204 & BGA7210
These 6-bit digital VGAs offer high linearity (35 dBm @ 2.2-2.8 GHz)
and high output power (23 dBm @ 2.2-2.8 GHz) across a large
bandwidth without external matching. Smart routing with no
connection crosses simplifies design and decreases footprint by 25%.
The unique power-save mode can effectively reduce the current
consumption in TDD systems up to 45%. The BGA7210 adds flexible
current distribution across its two amplifiers, depending on the
attenuation state, to save current.
`
Internally matched for 50 Ω
`
High maximum power gain
`
High output third-order intercept, IP3
O
`
Attenuation range of 31.5 dB, 0.5 dB step size (6 bit)
`
Fast switching power-save mode (power-down pin)
`
Digitally controlled current setting from 120 to 195 mA with an
optimum at 185mA (BGA7210 only)
`
Simple control interfaces (SPI)
`
ESD protection on all pins (HBM 4 kV; CDM 2 kV)
Features
