10Base-T Interface Module
E L E C T R O N I C S I N C .
EPE6370G
• General purpose 10Base-T Filter Module
• Complies with or exceeds IEEE 802.3, 10Base-T Standards
• Available in SMD and DIP Packages
Electrical Parameters @ 25° C
Insertion
Loss
Return
Loss
Attenuation
Crosstalk
Cut-Off
Frequency
(MHz)
(dB Min.)
(dB Min.)
(dB Max.)
(dB Min.)
1.0 MHz
Xmit/Rcv
17/17
1-10 MHz
Xmit/Rcv
-1/-1
5-10 MHz
Xmit/Rcv
-15/-15
@ 20 MHz
Xmit/Rcv
-7/---
@ 25 MHz
Xmit/Rcv
-15/-16
@ 30 MHz
Xmit/Rcv
-20/-10
@ 40 MHz
Xmit/Rcv
-30/-18
1-10 MHz
Xmit/Rcv
-30/-30
•
Isolation : 1500VAC
•
Cable Side Impedance : 100 Ω •
•* Referenced to the filter output @ 5 MHz for filter only, excluding resistor network
•
Schematic
Transmit Channel
Receive Channel
Chip Side
Cable Side
Chip Side
Cable Side
1
8
16
9
200Ω
200Ω
50Ω
50Ω
2
3
7
6
15
14
10
11
LPF
LPF
2:1
1:1
Package
.980
(24.89)
.092
.100
(2.54)
(2.34)
.140
(3.56)
PCA
Pad
.390
.560
EPE6370G
Date Code
Layout
(9.90)
(14.22)
Pin 1
I.D.
.030
(.762)
.700
(17.78)
.010/.015
.008/.012
.375
(.254/.381)
0°-8°
(.203/.305)
(59.53)
.035
(.889)
.510
(12.95)
.016/.022
(.406/.559)
.100
(2.54)
Unless Otherwise Specified Dimensions are in Inches /mm
.010 /.25
Product performance is limited to specified parameters. Data is subject to change without prior notice.
CSE6370G Rev. 1 5/6/03
