Aluminum Electrolytic Capacitors/ KS
Radial Lead Type
Series:
Low Profile
KS
Type:
A
5 mm height
KS
7 mm height
KA
M
Features
Endurance : 85° C 1000 h
5 mm height
RoHS directive compliant
Specifications
Category Temp. Range
Rated W.V. Range
Nominal Cap. Range
Capacitance Tolerance
DC Leakage Current
tan
δ
–40 °C to +85 °C
4 V.DC to 50 V.DC
0.1 µF to 330 µF
±20 % (120 Hz/+20 °C)
I
<
0.01 CV or 3 (µA) After 2 minutes (Whichever is greater)
Please see the attached standard products list
After applying rated working voltage for 1000 hours at +85 °C±2 °C, when the capacitors are
restored to 20°C capacitors, shall meet the following limits.
Endurance
Capacitance change ± 20% of initial measured value (4 V : ±30 %)
tan
δ
DC leakage current
Shelf Life
<
200 % of initial specified value
<
initial specified value
After storage for 1000 hours at +85 °C±2 °C with no voltage applied and then being stabilized
at +20 °C, capacitors shall meet the limits specified in Endurance (With voltage treatment)
Dimensions in mm (not to scale)
[mm]
Sleeve
φd±0.05
+
L±1.0
14 min.
3 min.
φD±0.5
F±0.5
(mm)
Body Dia.
φD
Lead Dia.
φd
Lead space F
4
0.45
1.5
5
0.45
2.0
6.3
0.45
2.5
8
0.45
2.5
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Apr. 2008
