PFS122
8bit MTP MCU with 12-bit R-Type ADC
xch
M
Exchange data between ACC and memory
Example: xch MEM ;
Result:
MEM ← a , a ← MEM
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
pushaf
Move the ACC and flag register to memory that address specified in the stack pointer.
Example: pushaf;
Result:
[sp] ← {flag, ACC};
sp ← sp + 2 ;
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
Application Example:
------------------------------------------------------------------------------------------------------------------------
.romadr 0x10 ;
// ISR entry address
pushaf ;
…
// put ACC and flag into stack memory
// ISR program
…
// ISR program
popaf ;
reti ;
// restore ACC and flag from stack memory
------------------------------------------------------------------------------------------------------------------------
Restore ACC and flag from the memory which address is specified in the stack pointer.
Example: popaf;
popaf
Result:
sp ← sp - 2
{Flag, ACC} ← [sp] ;
Affected flags: 『Y』Z 『Y』C 『Y』AC 『Y』OV
;
©Copyright 2020, PADAUK Technology Co. Ltd
Page 75 of 93
PDK-DS-PFS122-EN_V000-May 28, 2020
PADAUK [ PADAUK Technology ]
