LS K380, LO K380, LY K380, LG K380, LP K380
Lötbedingungen
Soldering Conditions
Wellenlöten (TTW) (nach CECC 00802)
TTW Soldering
(acc. to CECC 00802)
OHLY0598
300
C
10 s
Normalkurve
standard curve
250
200
150
100
50
T
235 C ... 260 C
Grenzkurven
limit curves
2. Welle
2. wave
1. Welle
1. wave
ca 200 K/s
2 K/s
5 K/s
100 C ... 130 C
Zwangskühlung
2 K/s
forced cooling
0
0
50
100
150
200
s
250
t
Empfohlenes Lötpaddesign Wellenlöten (TTW)
Recommended Solder Pad
TTW Soldering
4 (0.157)
OHLPY985
Maße werden wie folgt angegeben: mm (inch) / Dimensions are specified as follows: mm (inch).
