Leadform Options — TO–220 (Case 221A)
Leadform options require assignment of a special part number before ordering.
Contact your local Motorola representative for special part number and pricing.
10,000 piece minimum quantity orders are required.
Leadform orders are non–cancellable after processing.
•
•
•
•
•
Leadforms apply to both Motorola Case 221A–04 and 221A–06 except as noted.
LEADFORM AS
LEADFORM BC
.950 MIN.
1.00 MIN.
.100 REF.
.20 REF.
.736 ± .010
.620 ± .015
0.100 TYP.
0.750 MAX.
0.100 TYP.
.125 ± .010
MOUNTING
SURFACE
LEADFORM AJ
LEADFORM AU
CASE
A
CASE
A
221A–04 0.920 Min.
221A–06 0.885 Min.
221A–04
221A–06
0.360 ± 0.010
Lead Not Trimmed
0.300 Min.
.100 REF.
.200 REF.
.574
± .01
.765
± .01
A
.017
± .004
.580
± .010
.050 REF.
.06R
.095 REF.
A
LEADFORM 3 LEADS
.190 ± .020
Outline Dimensions and Leadform Options
5–6
Motorola Bipolar Power Transistor Device Data
