Reference Information
CPM2C CPU and Expansion I/O + G70A, G70D Relay I/O Blocks
CPM2C Connector type
CPM2C-ꢀC(1)DTC-D CPU Units with 16 pt DC IN/16 pt NPN OUT
CPM2C-ꢀE(D)TC Expansion I/O Modules with 16 pt DC IN/16 pt NPN OUT
G70D-VSOC16
OUTPUT
2 cables are required for each module
G79-100C (1 m)
G70A-ZOC16-3 +
G2R-1-S(N) relays
G79-150C (1.5 m)
G79-200C (2 m)
G79-300C (3 m)
G79-500C (5 m)
INPUT
G70A-ZOC16-3 +
G2R-1-S(N) relays
G70D-SOC16
CQM1H 16-point PNP Output Module + G70A Relay I/O Block
CQM1-OD214
(16 PNP outputs)
G79-Y100C (1 m)
G79-Y150C (1.5 m)
G79-Y200C (2 m)
G79-Y300C (3 m)
G79-Y500C (5 m)
G70A-ZOC16-4 +
G2R-1-S(N) relays
