Cable Solutions for Multi-Vendor PLCs
Siemens S7-300 and S7-400 Series PLCs
Communicates with Siemens HMI Adapter protocol. The Omron NT is communicating RS-232 to the Siemens HMI adapter,
6E57-972-OCA10-OXAO. The adapter is necessary to convert the HMI Adapter protocol into the Siemens proprietary MPI protocol.
Siemens S7-300 and S7-400 Series
MPI
NT631C-CN323-EU
NT31 (Port A)
NT631 (Port A or B)
6E57-972-0CA10-OXAO
NT31C-CN323-EU
NT31 (Port B)
Siemens S7-300 and S7-400 Communication Cables and Accessories
NT31C-CN323-EU
NT631C-CN323-EU
3.0 m cable, 25 to 9 pin, NT to Siemens PLC
3.0 m cable, 9 to 9 pin, NT to Siemens PLC
6E57-972-OCA10-OXAO HMI Adapter for MPI protocol (order from Siemens)
V060-E1-2
Operation Manual – Multi-vendor Connection
Mitsubishi A-Series PLCs
Communicates using Mitsubishi’s Computer Link protocol. The Omron NT and the Mitsubishi A-Series PLC are communicating using
RS-232 communications. Communications can be RS-422 by using custom cables as specified in Operation Manual V042-E1-1.
Mitsubishi A-Series
NT631C-CN324-EU
NT31 (Port A)
NT631 (Port A or B)
Computer Link Module
NT31C-CN324-EU
NT31 (Port B)
Mitsubishi A-Series Communication Cables and Accessories
NT31C-CN324-EU
NT631C-CN324-EU
V042-E1-1
3.0 m cable, 25 to 9 pin, NT to Mits-A PLC
3.0 m cable, 9 to 9 pin, NT to Mits-A PLC
Operation Manual – PC (Mitsubishi) Connection
17
