■ I/O Connectors for MULTIPLE I/O TERMINALs
Applicable Connectors
Type
Model
Remark
Connectable model
Housing
50-57-9403
16-02-0069
Corresponding to 24 to 30 AWG
Corresponding to 22 to 24 AWG
Corresponding to 24 to 30 AWG
Corresponding to 22 to 24 AWG
Corresponding to 22 to 26 AWG
Corresponding to 24to 30 AWG
Chain terminal
Digital I/O Units
GT1-ID16MX(-1)/GT1-OD16MX(-1)
16-02-0086
Crimped
terminals
Molex connector
16-02-0096
Loose terminal
Press-fit tool
Analog I/O Units
GT1-AD08MX/GT1-DA04MX
16-02-0102
57036-5000
57037-5000
Soldered terminals
FCN361J024-AU
FCN367J024-AU/F
FCN363J024-AU
FCN361J040-AU
FCN367J040-AU/F
FCN363J040-AU
XM2A-2501
Fujitsu connector
(16 points)
Pressure-welded terminals
Crimped terminals
Soldered terminals
Pressure-welded terminals
Crimped terminals
Pulg
Fujitsu connector
(32 points)
Digital I/O Units
GT1-ID32ML(-1)/GT1-OD32ML(-1)
OMRON
Digital I/O Units
D-sub connector
GT1-ID16DS(-1)/GT1-OD16DS(-1)
Hood
XM2S-2513
#4-40UNC inch screws
Applicable Cables with Connectors (Fujitsu Connectors)
I/O classification
Model
Connectable model
XW2Z-@@@A
G79-@C
Digital I/O Units
GT1-ID16ML(-1)
Digital input, 16 points
XW2Z-@@@A
G79-@C
XW2Z-@@@B
G79-I@C@
XW2Z-@@@B
G79-O@C@
Digital I/O Units
GT1-OD16ML(-1)
Digital output, 16 points
Digital input, 32 points
Digital output, 32 points
Digital I/O Units
GT1-ID32ML(-1)
Digital I/O Units
GT1-OD32ML(-1)
● Cables with Connectors (1-to1 Connection)/G79-@C
For Digital Input/Output (16 Points)
Appearance
Cable length (mm)
Model
G79-100C
G79-150C
G79-200C
G79-300C
G79-500C
1,000
1,500
2,000
3,000
5,000
L
● Cables with Connectors (1-to-2 Connection)/G79-O@C-@, G79-I@C-@
For Digital Input/Output (32 Points)
Cable length (mm)
Model
Appearance
Input
Output
A
B
G79-I100C-75
G79-O100C-75
G79-O150C-125
G79-O200C-175
G79-O300C-275
G79-O500C-475
A
1,000
750
G79-I150C-125
G79-I200C-175
G79-I300C-275
G79-I500C-475
1,500
2,000
1,250
1,750
2,750
4,750
3,000
5,000
B
Length without any bending
For Digital Input/Output (16 Points)
Appearance
Cable length (mm)
Model
XW2Z-050A
XW2Z-100A
XW2Z-150A
XW2Z-200A
XW2Z-300A
XW2Z-500A
500
1,000
1,500
2,000
3,000
5,000
L
For Digital Input/Output (32 Points)
Appearance
Cable length (mm)
Model
XW2Z-050B
XW2Z-100B
XW2Z-150B
XW2Z-200B
XW2Z-300B
XW2Z-500B
500
1,000
1,500
2,000
3,000
5,000
L
162
Peripheral Devices
OMRON [ OMRON ELECTRONICS LLC ]
