LPC546xx
NXP Semiconductors
32-bit ARM Cortex-M4 microcontroller
11.25 LCD
Table 52. Dynamic characteristics: LCD
Tamb = 40 C to 105 C; VDD = 2.7 V to 3.6 V; CL = 30 pF. Simulated values.
Symbol
Parameter
Conditions
Min
-
Typ
Max
50
Unit
MHz
ns
fclk
clock frequency
on pin LCD_DCLK
-
-
-
tv(Q)
data output valid time on all CCLK 100 MHz
LCD output pins
0.9
0.9
1.6
1.6
100 MHz < CCLK 180 MHz
ns
LPC546xx
All information provided in this document is subject to legal disclaimers.
© NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet
Rev. 2.5 — 20 June 2018
135 of 169
