Figure 19. Erase Suspend & Resume Flowchart and Pseudo Code
Start
erase_suspend_command ( ) {
writeToFlash (any_address, 0xB0) ;
Write B0h
Write 70h
writeToFlash (any_address, 0x70) ;
/* read status register to check if
erase has already completed */
do {
Read Status
Register
status_register=readFlash (any_address) ;
/* E or G must be toggled*/
NO
NO
} while (status_register.b7== 0) ;
b7 = 1
YES
if (status_register.b6==0) /*erase completed */
{ writeToFlash (any_address, 0xFF) ;
b6 = 1
YES
Erase Complete
read_data ( ) ;
/*read data from another block*/
/*The device returns to Read Array
(as if program/erase suspend was not issued).*/
Write FFh
Read data from
another block
or
Program/Protection Program
or
Block Protect/Unprotect/Lock
}
else
{ writeToFlash (any_address, 0xFF) ;
read_program_data ( );
Write D0h
Write FFh
Read Data
/*read or program data from another address*/
writeToFlash (any_address, 0xD0) ;
/*write 0xD0 to resume erase*/
}
}
Erase Continues
AI03542b
