Part Numbering
M29FxxxFT, M29FxxxFB
9
Part Numbering
Table 22. Information scheme
Example:
M29F200F T
5A
M
6
-
2
Device type
M29F = 5 V
Density
200 = 2-Mbit
400 = 4-Mbit
800 = 8-Mbit
160 = 16-Mbit (not available in SO44 package)
Technology
F = 110 nm
Configuration
T = Top Boot
B = Bottom Boot
Speed
55 = 55 ns device speed in conjunction with
temperature range = 3 denotes Auto Grade –40 to
125 °C parts
5A = 55 ns Access time (Auto Grade) only in
conjunction with the Grade 6 option
Package
M = SO 44.525 INCH CU
N = TSOP-1 48 12 x 20 AL 4
ZA(1) = TFBGA48, 6 x 8 mm, 0.80 mm pitch
Temperature range
6 = –40 to 85 °C
3 = –40 to 125 °C
Packing option
<blank> = standard packing (Tray)
T = Tape & Reel 24 mm packing
E = RoHS package, standard packing (Tray)
F = RoHS package, Tape & Reel 24 mm packing
Fab location
2 = Numonyx Fab.2 (Singapore)
1. THis package is available only in the 8-Mbit, bottom boot configuration.
Devices are shipped from the factory with the memory content bits erased to ’1’.
For a list of available options (Speed, Package, etc.) or for further information on any aspect
of this device, please contact the Numonyx Sales Office nearest to you.
