COP8 Device Programmer Support
16.0 Development Support (Continued)
•
MetaLink’s EPU and Debug Module include development
device programming capability for COP8 devices.
•
COP8-MLSIM: Free Instruction Level Simulator tool for
Windows. For testing and debugging software instruc-
tions only (No I/O or interrupt support).
•
Third-party programmers and automatic handling equip-
ment cover needs from engineering prototype and pilot
production, to full production environments.
COP8 Real-Time Emulation Tools
•
COP8-DM: MetaLink Debug Module. A moderately
•
Factory programming available for high-volume require-
ments.
priced real-time in-circuit emulation tool, with COP8 de-
vice programmer. Includes MetaLink Debugger, power
supply, emulation cables and adapters.
IM-COP8: MetaLink iceMASTER®. A full featured, real-
time in-circuit emulator for COP8 devices. Includes
COP8-NSDEV, Driveway COP8 Demo, MetaLink Win-
dows Debugger, and power supply. Package-specific
probes and surface mount adaptors are ordered sepa-
rately.
16.3 TOOLS ORDERING NUMBERS FOR THE
COP8FGx FAMILY DEVICES
•
The COP8FGx devices are faster speed versions of the
COP8SGx devices, and the existing SGx tools can be used
without updating or modification (just use the SGx menus).
The COP8SG-DM and IM-COP8/400 ICE can be used for
emulation with the limitation of 10 MHz emulation speed
maximum. For full speed COP8FGx emulation, use the 15
MHz COP8FG-DM.
Note: The following order numbers apply to the COP8 devices in this datasheet only.
Vendor
Tools
Order Number
COP8-NSEVAL
Cost
Notes
National COP8-NSEVAL
COP8-NSASM
Free Web site download
COP8-NSASM
Free Included in EPU and DM. Web site download
Free Included in EPU and DM. Web site download
COP8-MLSIM
COP8-MLSIM
COP8-NSDEV
COP8-NSDEV
VL
VL
Included in EPU and DM. Order CD from website
COP8-EPU
COP8SG-EPU (-1 or -2)
-1 = 110V, -2 = 220V; Included p/s, 40 pin DIP target
cable, manuals, software, 16/20/28/40 DIP OTP
programming socket; add DM target adapter or OTP
adapter (if needed)
COP8-DM
COP8SG-DM (10 MHz)
M
Included p/s, 28/40/44 pin DIP/SO/PLCC target
cables, manuals, software, 16/20/28/40 DIP/SO and
44 PLCC programming socket; add OTP adapter or
target adapter (if needed)
DM Target
Adapters
DM-COP8/20D-SO
DM-COP8/20D-16D
DM-COP8/20D
VL
VL
VL
L
20 pin DIP to SO converter
20 pin DIP to 16 pin DIP converter
20 pin DIP target cable
DM-COP8/28D-28CSP
DM-COP8/44P-44Q
COP8FGx7
28 pin DIP to 28 pin CSP converter
44 pin PLCC to 44 QFP converter
8k or 32k Eraseable or OTP devices
L
Development
Devices
VL
OTP
Programming
Adapters
COP8SA-PGMA
L
For programming 16/20/28 SOIC and 44 PLCC on the
EPU
COP8-PGMA-44QFP
COP8-PGMA-28CSP
COP8-PGMA-28SO
Call MetaLink
L
For programming 44 QFP on any programmer
For programming 28 CSP on any programmer
For programming 16/20/28 SOIC on any programmer
L
VL
IM-COP8
