Electrical Specifications (Continued)
6.2.2 NC-Designated Pins
Table 6-2. Pins with > 20-kohm Internal Resistor
Pins designated NC (No Connection) should be left dis-
connected. Connecting an NC pin to a pull-up/-down
resistor, or an active signal could cause unexpected
results and possible circuit malfunctions.
Signal Name
BGA Ball No.
PU/PD
SUSP#
FRAME#
IRDY#
H2
A8
Pull-up
Pull-up
Pull-up
Pull-up
Pull-up
Pull-up
Pull-up
Pull-up
Pull-up
Pull-up
Pull-up
Pull-up
Pull-up
Pull-down
6.2.3 Pull-Up and Pull-Down Resistors
C9
Table 6-2 lists the input pins that are internally connected
to a weak (>20-kohm) pull-up/-down resistor. When
unused, these inputs do not require connection to an
external pull-up/-down resistor.
TRDY#
STOP#
LOCK#
DEVSEL#
PERR#
SERR#
REQ[2:0]#
TCLK
B9
C11
B11
A9
6.2.4 Unused Input Pins
All inputs not used by the system designer and not listed
in Table 6-2 should be kept at either ground or VCC3. To
prevent possible spurious operation, connect active-high
inputs to ground through a 20-kohm (±10%) pull-down
resistor and active-low inputs to VCC3 through a 20-kohm
(±10%) pull-up resistor.
A11
C12
D3, H3, E3
J2
TMS
H1
TDI
D2
TEST
F3
