MUSES02
ꢀ AC CHARACTERISTICS (V+/V-=±15V, Ta=25°C unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITION
MIN.
TYP.
MAX.
UNIT
Gain Bandwidth Product
GB
f=10kHz
-
11
-
MHz
AV=+100, RS=100Ω,
RL=2kΩ, CL=10pF
Unity Gain Frequency
Phase Margin
fT
-
-
-
5.8
48
-
-
-
MHz
deg
AV=+100, RS=100Ω,
RL=2kΩ,CL=10pF
φM
VNI
f=1kHz, AV=+100,
RS=100Ω,RL=∞
Input Noise Voltage1
4.5
nV/√Hz
f=1kHz, AV=+10
RS =2.2kΩ,
RIAA, 30kHz LPF
Input Noise Voltage2
VN2
-
0.8
1.4
μVrms
f=1kHz, AV=+10,
RL=2kΩ, Vo=5Vrms
Total Harmonic Distortion
Channel Separation
Positive Slew Rate
THD
CS
-
-
-
-
0.001
150
5
-
-
-
-
%
f=1kHz, AV=-+100,
RS=1kΩ, RL=2kΩ
dB
AV=1, VIN=2Vp-p,
RL=2kΩ, CL=10pF
+SR
-SR
V/μs
V/μs
AV=1, VIN=2Vp-p,
RL=2kΩ, CL=10pF
Negative Slew Rate
5
Ver.2009-12-18
- 3 -
NJRC [ NEW JAPAN RADIO ]
