Nichia STSE-CC2006B
<Cat.No.031031>
6.RELIABILITY
(1) TEST ITEMS AND RESULTS
Standard
Number of
Test Item
Resistance to
Soldering Heat
(Reflow Soldering)
Solderability
Test Method
JEITA ED-4701
300 301
Test Conditions
Tsld=260°C, 10sec.
(Pre treatment 30°C,70%,168hrs.)
Note
2 times
Damaged
0/50
JEITA ED-4701
300 303
JEITA ED-4701
300 307
JEITA ED-4701
100 105
JEITA ED-4701
200 203
JEITA ED-4701
200 201
JEITA ED-4701
100 103
JEITA ED-4701
200 202
Tsld=215 ± 5°C, 3sec.
(Lead Solder)
0°C ~ 100°C
1 time
over 95%
20 cycles
0/50
0/50
0/50
0/50
0/50
0/50
0/50
0/50
0/50
0/50
0/50
0/50
0/50
(Reflow Soldering)
Thermal Shock
15sec. 15sec.
Temperature Cycle
-40°C ~ 25°C ~ 100°C ~ 25°C
30min. 5min. 30min. 5min.
25°C ~ 65°C ~ -10°C
90%RH 24hrs./1cycle
Ta=100°C
100 cycles
10 cycles
1000 hrs.
1000 hrs.
1000 hrs.
1000 hrs.
1000 hrs.
1000 hrs.
500 hrs.
Moisture Resistance Cyclic
High Temperature Storage
Temperature Humidity
Storage
Low Temperature Storage
Ta=60°C, RH=90%
Ta=-40°C
Steady State Operating Life
Condition 1
Steady State Operating Life
Condition 2
Steady State Operating Life
of High Temperature
Steady State Operating Life
of High Humidity Heat
Steady State Operating Life
of Low Temperature
Vibration
Ta=25°C, IF=20mA
Ta=25°C, IF=30mA
Ta=85°C, IF=7.5mA
60°C, RH=90%, IF=20mA
Ta=-30°C, IF=20mA
1000 hrs.
48min.
JEITA ED-4701
400 403
100 ~ 2000 ~ 100Hz Sweep 4min.
200m/s2
3direction, 4cycles
3mm, 5 ± 1 sec.
Substrate Bending
Stick
JEITA ED-4702
JEITA ED-4702
1 time
1 time
0/50
0/50
5N, 10 ± 1 sec.
(2) CRITERIA FOR JUDGING THE DAMAGE
Criteria for Judgement
Min. Max.
Item
Symbol Test Conditions
Forward Voltage
Reverse Current
Luminous Intensity
VF
IR
IF=20mA
-
U.S.L.*)ꢂ1.1
U.S.L.*)ꢂ2.0
-
VR=5V
-
IV
IF=20mA
L.S.L.**)ꢂ0.7
*) U.S.L. : Upper Standard Level
**) L.S.L. : Lower Standard Level
-3-
