µPD75216A
14. PACKAGE INFORMATION
64 PIN PLASTIC SHRINK DIP (750 mil)
64
33
32
1
A
K
L
F
D
M
R
B
C
M
N
NOTE
ITEM MILLIMETERS
INCHES
1) Each lead centerline is located within 0.17 mm (0.007 inch) of
its true position (T.P.) at maximum material condition.
A
B
C
58.68 MAX.
1.78 MAX.
1.778 (T.P.)
2.311 MAX.
0.070 MAX.
0.070 (T.P.)
2) Item "K" to center of leads when formed parallel.
+0.004
0.020
D
0.50±0.10
–0.005
F
G
H
I
0.9 MIN.
3.2±0.3
0.035 MIN.
0.126±0.012
0.020 MIN.
0.170 MAX.
0.200 MAX.
0.750 (T.P.)
0.669
0.51 MIN.
4.31 MAX.
5.08 MAX.
19.05 (T.P.)
17.0
J
K
L
+0.004
0.010
+0.10
0.25
M
–0.003
–0.05
N
R
0.17
0.007
0~15°
0~15°
P64C-70-750A,C-1
63
