Standard Parts List
◦ASB series
Displacemen［t μm］
Resonance
frequency
［kHz］
Insulation
resistance
［MΩ］
Generated force
Capacitance
［μF］
Model
Maximum driving voltage
［N］
［150VDC］
ASB170C801■●0LF
ASB170C801W●1-A0LF
ASB340C801■●0LF
ASB340C801W●1-A0LF
ASB510C801■●0LF
ASB510C801W●1-A0LF
ASB680C801■●0LF
ASB680C801W●1-A0LF
ASB170C201WP1-A0LF
17.0±3
34.0±6
51.0±9
800
800
800
14
12
10
1.5
3.0
4.5
30
15
10
68.0±12
20.0±3
800
200
8
6.0
0.5
5
37
100
*Note: ■ in model number has “N” or “F” letter.
● in model number has “P” or “D” letter.
Example）ASB170C801NP0LF, ASB510C801WD1-A0LF
*Model number, ASB＊＊＊C801W●1-A1LF is the model without a flange.
*For detail information of measurement conditions and outer dimension, please refer to “Performance” and “Outer Dimension” sections.
◦ASL series
Displacemen［t μm］
Resonance
frequency
［kHz］
Insulation
resistance
［MΩ］
Generated force
Capacitance
［μF］
Model
Maximum driving voltage
［N］
［150VDC］
ASL170C801■●0LF
ASL340C801■●0LF
ASL510C801■●0LF
ASL680C801■●0LF
19.0±3
39.0±6
58.0±9
77.0±12
800
800
800
800
14
12
10
8
1.34
2.55
3.84
5.07
30
15
10
5
*Note: ■ in model number has “N” or “F” letter.
● in model number has “P” or “D” letter.
Example）ASL170C801FP0LF
*No flange type is also available for ASL-series. Please contact us for detail.
◦AHB series
Displacemen［t μm］
Resonance
frequency
［kHz］
Insulation
resistance
［MΩ］
Generated force
Capacitance
［μF］
Model
Maximum driving voltage
［N］
［150VDC］
AHB550C801■●0LF
AHB700C801■●0LF
AHB800C801■●0LF
AHB800C302WD1-A0LF
55.0±8
70.0±15
80.0±15
80.0±15
800
800
12
8
6.4
8.2
10
5
800
8
9.3
5
3000
8
37.0
2
*Note: ■ in model number has “N” or “F” letter.
● in model number has “P” or “D” letter.
Example）AHB800C801NP0LF
*No flange type is also available for AHB-series. Please contact us for detail.
*For detail information of measurement conditions and outer dimension, please refer to “Performance” and “Outer Dimension” sections.
Flange type
No flange type
Product appearance example
12 Multilayer Piezoelectric Actuators Vol.06
