Please read CAUTION and Notice in this catalog for safety. This catalog has only typical specifications. Therefore you are requested
to approve our product specification or to transact the approval sheet for product specification, before your ordering.
P61E7.pdf 01.10.17
Ceramic Filters (CERAFILr) for FM Receivers
CERAFILr Wider Band-width Type
7.0±2.0
SFELA10M7 Series for FM-receivers are monolithic type
ceramic filters which use the energy trapped thickness
vibration-mode of the piezoelectric ceramic.
M A R K I N G
E I A J
C O D E
1.38±0.2
1.7±0.1
■ Features
1. Realizes wider or narrower band characteristics not
obtained by conventional ceramic filters.
2. Temperature characteristics are the best available,
0.5±0.1
2.5±0.2 2.5±0.2
(1) : Input
(2) : Ground
(3) : Output
the same as those of Murata's conventional ceramic
filters. Thus, even in the case of narrow band
filters, the center frequency is stable even if
temperature changes.
SFELA10M7EA00-B0
(in mm)
(3)
(2)
(1)
7.0±2.0
M A R K I N G
E I A J
C O D E
7
1.38±0.2
1.7±0.1
0.5±0.1
2.5±0.2 2.5±0.2
(1) : Input
(2) : Ground
(3) : Output
SFELA10M7DF00-B0
(in mm)
(3)
(2)
(1)
Nominal
Center Frequency(fn)
(MHz)
Center Frequency (fo)
(MHz)
3dB Bandwidth Attenuation Insertion Loss Spurious Attenuation
Part Number
(kHz)
(kHz)
(dB)
(dB)
SFELA10M7EA00-B0
SFELA10M7DF00-B0
10.700 ±30kHz
-
within330 ±50kHz
fn±175 min.
680 max. within4.0 ±2.0dB
950 max. within3.0 ±2.0dB
30 min.
20 min.
-
10.700
Area of Attenuation : [within 20dB]
Area of Spurious Attenuation : [within 9MHz to 12MHz]
Center frequency(fo) defined by the center of 3dB bandwidth.
(fn) means nominal center frequency.
■ Center Frequency Rank Code
CODE
30kHz Step
25kHz Step
D
B
A
C
E
Z
10.64MHz±30kHz
10.67MHz±30kHz
10.70MHz±30kHz
10.73MHz±30kHz
10.76MHz±30kHz
10.650MHz±25kHz
10.675MHz±25kHz
10.700MHz±25kHz
10.725MHz±25kHz
10.750MHz±25kHz
Combination A,B,C,D,E
Combination A,B,C
M
23
