Please read CAUTION and Notice in this catalog for safety. This catalog has only typical specifications. Therefore you are requested
to approve our product specification or to transact the approval sheet for product specification, before your ordering.
P61E7.pdf 01.10.17
Ceramic Filters (CERAFILr) for FM Receivers
CERAFILr Low-profile Type
7.5±2.0
SFELB10M7 series for FM-receivers are monolithic type
ceramic filters which use the energy trapped thickness
vibration-mode of the piezoelectric ceramic.
E I A J
C O D E
M A R K I N G
1.5±0.1
1.3±0.1
Features
0.5±0.1
1. Installed height is 5 mm, making it well suited for
compact, thin sets.
2.5±0.2 2.5
±0.2
2. Environmental reliability is the same as those of
(1) : Input
(2) : Ground
(3) : Output
the ceramic filter SFELA10M7 series.
SFELB10M7KA00-B0
SFELB10M7HA00-B0
SFELB10M7FA00-B0
5
in mm
(1)
(2)
(3)
7.5±2.0
7.5±2.0
E I A J
C O D E
E I A J
C O D E
M A R K I N G
M A R K I N G
1.5±0.1
1.3±0.1
1.5±0.1
1.3±0.1
0.5±0.1
0.5±0.1
2.5
±
0.2 2.5
±
0.2
2.5±0.2 2.5
±0.2
(1) : Input
(2) : Ground
(3) : Output
(1) : Input
(2) : Ground
(3) : Output
SFELB10M7JA00-B0
in mm
in mm
(1)
(2)
(3)
(1)
(2)
(3)
7.5±2.0
7.5±2.0
E I A J
C O D E
E I A J
C O D E
M A R K I N G
M A R K I N G
1.5±0.1
1.3±0.1
1.5±0.1
1.3±0.1
0.5±0.1
0.5±0.1
2.5
±
0.2 2.5
±
0.2
2.5±0.2 2.5
±0.2
(1) : Input
(2) : Ground
(3) : Output
(1) : Input
(2) : Ground
(3) : Output
SFELB10M7GA00-B0
in mm
in mm
(1)
(2)
(3)
(1)
(2)
(3)
Center Frequency (fo)
(MHz)
3dB Bandwidth
(kHz)
Attenuation
(kHz)
Insertion Loss
(dB)
Spurious Attenuation
(dB)
Part Number
SFELB10M7KA00-B0
SFELB10M7JA00-B0
SFELB10M7HA00-B0
SFELB10M7GA00-B0
SFELB10M7FA00-B0
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
within110 ±30kHz
within150 ±40kHz
within180 ±40kHz
within230 ±50kHz
within280 ±50kHz
350 max.
360 max.
470 max.
570 max.
650 max.
within7.0 ±2.0dB
within4.5 ±2.0dB
within3.5 ±2.0dB
within3.0 ±2.0dB
within3.0 ±2.0dB
30 min.
35 min.
35 min.
40 min.
30 min.
Area of Attenuation : [within 20dB]
Area of Spurious Attenuation : [within 9MHz to 12MHz]
Center frequency(fo) defined by the center of 3dB bandwidth.
17
