Continued from the preceding page.
yRated Voltage
uCapacitance
Expressed by three-digit alphanumerics. The unit is pico-farad
(pF). The first and second figures are significant digits, and the
third figure expresses the number of zeros which follow the two
numbers.If there is a decimal point, it is expressed by the capital
letter "R". In this case, all figures are significant digits.
Code
0E
Rated Voltage
DC2.5V
0G
0J
DC4V
DC6.3V
Ex.)
1A
1C
1E
DC10V
Code
R50
1R0
100
Capacitance
0.5pF
DC16V
DC25V
1.0pF
YA
1H
2A
2D
2E
DC35V
10pF
DC50V
103
10000pF
DC100V
DC200V
DC250V
YD
2H
2J
DC300V
DC500V
DC630V
DC1kV
3A
3D
3F
DC2kV
DC3.15kV
BB
E2
DC350V (for Camera Flash Circuit)
AC250V
GB
GC
GD
GF
X2; AC250V (Safety Standard Certified Type GB)
X1/Y2; AC250V (Safety Standard Certified Type GC)
Y3; AC250V (Safety Standard Certified Type GD)
Y2, X1/Y2; AC250V (Safety Standard Certified Type GF)
Continued on the following page.
